Column Pipes

Your Quality Pipe Professionals. Since 2023 Quality Meets Affordability.

Specifications :

  • Self-extinguishing does not support combustion.
  • High tensile strength and high pressure rating.
  • Excellent pull out strength.
  • Adjustable according to the depth of water level.
  • High tensile strength of pipe coupler locking, so lock safety is 100%.
  • Low friction losses due to excellent smooth internal surface.
  • Resistant to chemcial reaction, Bacterial growth, Corrosion, Rusting etc.
  • Size 1" (33mm) To 4" (113mm) are available with various range like economy, Medium, Standard, Super Standard, Heavy & Super Heavy.

Application :

  • Water rising for suvmersible and jet pump Irrigation, Domestic, Industrial, Mining & Chemical distribution.
  • uPVC is nearly inert towards Corrosion, Chemical reaction and erosion. Hence it is ideally suited for long term use in salty, Sandy and Chemically aggressive water.

Salient Features :

  • High Load Bearing Strength: Along with the durability and a strong threading system, These pipes are also able to take on heavy instantaneous or prolonged pressures.
  • Easy Installation: Solvent jointing is the easiest process and plays the trick in lying large length of pipe in short time
  • Non Corrosive: ETHAN column pipes being chemically inert, resist corrosion require no manitenance thereby longer life than conventional pipe.
  • Smooth Inner Surface: ETHAN column pipes have very smooth internal surface which allow friction loss flow with energy saving and tensil strength therby stamina flow.
  • Light in Weight: ETHAN column pipes are light in weight as compare to GI pipes and other pipes there by transportation & installation are easy
  • Square Thread: Internal (inner surface of coupler) and External (outer surface of pipe) aquare threaded spigot ends& rubber gaskets for easy reliable and pressure sealing thereby under deep bore pulling load capacity is high. The square threads of coupler & pipes are specially made by CNC machine.
  • Cost Effective: Low additional cost incurred in installation.
  • Economic: ETHAN column pipes are the best quality pipe with economic price.

Specifications

SIZE (INCH) MM (OD) TYPES OF PIPE kgf/cm^2 MAXIMUM DEPTH OF INSTALLATION (FEET) PACKING
1" 33MM Bell 12.5 kg 12.5 150 40
ECO 16 200 30
MED 21 300 25
Bell 15 kg 15 200 25
STD 30 600 25
1.25" 42MM Bell 12.5 kg 12.5 150 25
ECO 15 200 25
MED 21 300 20
Bell 15 kg 15 200 25
STD 25 500 20
HVY 35 900 15
1.5" 48MM Bell 12.5 kg 12.5 150 20
ECO 15 250 15
MED 21 350 15
Bell 15 kg 15 200 20
STD 27 650 15
HVY 35 900 15
2" 60MM ECO 9, 11, 13 150, 200, 200 15
MED 17 350 15
STD 21 650 10
SUP.STD 28 800 10
HVY 32 900 10
SUP.HVY 32, 37 1000, 1200 7
2.25" 63MM STD 20 600 10
HVY 28 900 10
SUP.HVY 37 1200 7
2.5" 75MM ECO 12 200 10
MED 14 300 10
STD 21 600 10
HVY 32 900 7
SUP.HVY 32, 37 1000, 1200 5
3" 88MM ECO 10 200 5
MED 12 300 5
STD 17 500 5
HVY 26 850 5
SUP.HVY 37 1100 5
4" 113MM ECO 9 200 5
MED 11 300 5
STD 16 500 5
HVY 26 850 3
SUP.HVY 37 1100 3
5" 140MM STD 17 520 2
HVY 27 850 2
6" 165MM STD 17 500 2
HVY 27 800 2
